DTXA (0.5 N⋅m - 10 N⋅m)
IMADA DTXA (0.5 N⋅m - 10 N⋅m)
DTXA-series
High-function screw cap torque tester has capacity of 50N-cm to 1000N-cm (10N-m). Capable of measuring opening and closing torque of container lids such as PET bottles and jars. In addition to the high measurement repeatability by high-speed sampling and various data output methods of the standard type (DTXS series), it features angle input/output and USB memory connection. Next Series with firmware Ver. 5 or later offers improved measurement stability due to low noise, and expandability and convenience through additional functions (firmware download) and various software and instruction manual from the dedicated website (IMADA Connected).
Features
- High sampling rate (2000Hz) for accurate results, capturing small changes and accurate peak values by following rapid changes of torque
- Ideal for measuring opening/closing torque of various samples such as bottles and bins
- Reduces risk of misreading values with easy-to-read high luminance organic EL display. Allows customers to customize the contents for the three sections of the display screen
- Handles a wide range of samples with various optional tables and attachments
- Equips additional functions such as angle I/O (angle meter required), direct connection to USB flash drive, and 1st and 2nd peak value detection
